I added Docker configuration to AeroAssist in PR #37 to package the application and SQL Server together. For screenshots and my implementation work, see the AeroAssist case study.

These notes describe files at dff52cb. They are a source review, not a verified deployment walkthrough.

What the configuration provides

#
  • The Dockerfile restores and publishes with the .NET 8 SDK, copies output into the ASP.NET 8 runtime image, and runs as appuser.
  • Compose defines aeroassist and sqlserver services, a shared network, and the sqlserver-data volume.
  • SQL Server uses the 2022 image with the Express edition setting. The app waits for the database health check and applies migrations when configured.
  • The app listens on port 8080. Compose also publishes SQL Server on port 1433.

Start and stop

#

Use a Docker host compatible with the SQL Server image. The Compose file accepts SQL Server license terms and publishes both ports.

git clone https://github.com/lh1207/AeroAssist.git
cd AeroAssist
cp .env.example .env
# Replace SA_PASSWORD in .env with your own strong password.
docker compose up --build -d
docker compose logs

The configured addresses are http://localhost:8080 and http://localhost:8080/swagger. Use docker compose down to stop services while retaining the database volume.

Configuration the code reads

#

These keys come from Program.cs and the page models:

  • ConnectionStrings__DefaultConnection: SQL Server connection string.
  • Database__AutoMigrate: apply EF migrations at startup.
  • HttpClient__BaseAddress: API address used by server-side page models. Compose sets http://aeroassist:8080/.
  • Swagger__Enabled: expose Swagger outside Development.
  • ReverseProxy__Enabled: skip the production HSTS/HTTPS redirect branch. This alone does not configure forwarded headers.
  • Authentication__Microsoft__ClientId and Authentication__Microsoft__ClientSecret: optional Microsoft sign-in, registered when both are present.

Compose runs in the Production environment and supplies settings through environment variables. appsettings.Docker.json is a reference file, not the active environment configuration for this Compose setup.

Manual .NET setup

#

Use a .NET 8 SDK and an accessible SQL Server instance. Configure ConnectionStrings:DefaultConnection with local user secrets or environment variables before applying migrations. Restore packages, install a .NET 8-compatible dotnet-ef tool, and run dotnet ef database update.

The repository defines https-website (ports 5000/5001) and https-api (7222/7223) launch profiles. The default page-model client and chart scripts expect the API on https://localhost:7223; starting only the website profile is insufficient. For these defaults, start both profiles in separate terminals:

dotnet run --launch-profile https-api
# In a second terminal:
dotnet run --launch-profile https-website

Local HTTPS requires a trusted development certificate. This sequence is derived from the checked-in configuration and was not executed during this review.

Remaining demonstration issues

#
  • Chart scripts hardcode https://localhost:7223/api/Ticket/Ticket, bypassing the configurable server-side API address.
  • The application health check requires curl, but the Dockerfile does not install it.
  • Compose has a default database password fallback and enables the page-model certificate-validation bypass. Replace demo defaults and review authorization before public deployment.
  • The .NET SDK was unavailable and Docker was not running during this website update, so a successful build and end-to-end run remain unverified.
